DESCRIPTION

• Overview
• Product Description
• Detailed Photos

Overview

Basic Info.

Model NO.	Magnetic track
Power	48W
Emitting Color	White /Black
Base Type	Track Bar
Wire	4 Wired
IP Rating	IP26
Certification	CCC, CE, REACH, RoHS
Input Voltage	48V
LED Chips Brand	Osram
Length	1m/2m/3m
Warranty	3 Years
Color	White /Black
Light Source	LED
Application	Shop, Office.Residential, Indoor
Working Lifetime(Hour)	300000 Hours
Transport Package	Color Box
Specification	Magnetic Track Light KITS
Trademark	Degco
Origin	Foshan China
Production Capacity	500000PCS/Month

Packaging & Delivery

Package Size302.00cm * 40.00cm * 55.00cm Package Gross Weight2.000kg

Product Description

Magnetic track lamp, as the name suggests, attaches the lamp component to the track through the magnetic way, in the case of ensuring reliable connection, more convenient and flexible installation and disassembly of the lamp component, convenient for daily maintenance and maintenance. Through magnetic technology, the lamp assembly can be adsorbed on the track. The lamp is easy to disassemble and assemble, and can be fixed with one insert. At the same time, because the track is low-voltage power supply, the lamp body can be removed from the drive, so the entire track and lamps can be made very small and delicate, very suitable for home use.

Product Description Magnetic track light features include: 1 Installation is simple, only need to lay the track in advance, the lamp suction up, take down, a second to finish. 2 Can be equipped with different lamps, which are suitable for many light source modules of magnetic lamps, including downlights, spotlights, grid lights, floodlights, chandelier lines and so on. 3 The number of lamps can be freely increased or decreased, and there is no limit to the number of lamps installed on the track. 4 Can move freely, freely adjust the Angle, the light source can move freely, according to the space needs of the free lighting. 5 Low voltage safety, no contact risk. Detailed Photos

Product Name	Magnetic Track Lighting System	Colour	black/white
Power head	Brown wire/Blue wire for Power, Yellow wire/Black wire for signal	Black	InputDC48V
I Typen Power Connector	Rail and rail splicing use	Black	InputDC48V
Flexiable Power Connector	Corner stitching use	Black	InputDC48V
Surface Mounted Type Corner	Surface mounting/suspend	Black	80*80mm
Recessed Ceiling Corner	cut out34mm	Black	100*100mm
Recessed Wall Corner	cut out34mm	Black	100*100mm
T Connector	/	Black	160*100mm
X Connector	/	Black	160*160mm
PC Cover	R20/35 PC cover	Black	3M/PCS
End Cup	Connecting Piece	MATTE BLK	/
Hanging Part	2M	/	2M
Transformer	48V 150W/200W/350W
RECESSED TYPE DRIVER	48V 100W/200W
Surface Mounted Track Rail		MATTE BLK	1M/1.5M/2M/3M
Recessed Track Rail	cut out38-40mm	MATTE BLK	1M/1.5M/2M/3M
